SKU: PEPWAVE-MAX-BR1-MINI-LTEA-W-T-PRM
(13)

Pepwave Max BR1 Mini Cat 6 LTE Advanced Router + PrimeCare + 12V Power Supply

Pepwave
Sale
In stock
$349.00
$349.00 $419.00

Add a Data Plan to Your Pepwave (Cost Prorated Based on Order Date)

$24.97
$38.52
$24.97
$32.71
$32.71

Device Configuration

Payment details

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Help your customers identify what payments are accepted by your store.



The Max BR1 Mini is perfect for RVers and travelers looking to use cellular data to stay connected on the road. You can load up to 2 SIM cards into this router from multiple carriers and select which SIM card and carrier to use. This router will turn your cellular signal into a secure WiFi network of your own, right inside of your RV.

Cat 6 Single Cell Modem

  •  The Max BR1 Mini has a single Cat 6 cellular modem.  A single cellular modem means you can only use one SIM card (cellular plan) at a time to access the internet.

    Note: This unit takes the smallest "Nano" SIM card.

  • Although the Max BR1 Mini only has one cellular modem, it allows you to use 2 SIM cards (cellular plans) in the one modem and switch between the two plans as needed.  This allows for the redundancy often needed to stay connected while on the road.  You can also set limits and rules for when you want to use one cell plan over the other which is a great feature when you are trying to conserve one plan and only use it as a backup.  You are not using both cell plans at the same time with this router; however, there are routers available that allow you to use 2 SIM cards at the same time which will improve your connectivity. (See the Max Transit DUO routers.)

What is the optional Failover License?

  • The Max BR1 Mini does not come out of the box with WiFi as WAN capabilities, which means you cannot use it to access campground or local WiFi networks. You can add an optional failover software license for $99, which enables Ethernet and unlocks the WiFi as WAN feature. The failover license will allow you to use the BR1 Mini to connect to campground WiFi using a dual band connection (2.4 and 5 GHz).
  • If you plan to use your Max BR1 Mini for cellular only, then you do not need to purchase the additional $99 failover license. If you choose to not add it at the time of purchase, don’t worry; you can add it at any time.
  • This is a digital item that is permanently connected to the router it is purchased for. For this reason, failover licenses are nonrefundable and nontransferrable.

Supports All Major Carrier Networks

  • US Carriers: AT&T, Verizon, T-Mobile, Sprint, and US Cellular
  • International Carriers: Rogers, TELUS, and Bell

Supports Carrier Aggregation

  • Cat 6 routers like the Max BR1 Mini support Carrier Aggregation (CA), which means they have the ability to connect to 2 cellular bands at the same time.  By combining more than one cellular band together, it is possible to increase the bandwidth available.  With the Max BR1 Mini you can choose which primary band you want to use (the tower selects the second) which allows you to avoid the crowded primary band used by phones and hotspots.  To see the bands supported by the Max BR1 Mini, see the specs listed below.

Increased Throughput and Speeds

  • Because of Carrier Aggregation, the Max BR1 Mini has higher throughput and speeds than a Cat 4 router or phone.
  • The Max BR1 Mini has theoretical download speeds of 300 Mbps and upload speeds of 50 Mbps.
  • This router features Wifi 6, the latest and greatest wifi technology, promising faster, more efficient wifi performance.


KIT CONTENTS:

  • Pepwave MAX BR1 Mini Router
  • 1x Molex (4-pin) to AC Wall-Style Power Supply
  • 1x 12V Molex 4-Pin to Cigarette-Style Power Supply
  • 1x GPS Antenna
  • 2x WiFi Antennas
  • 2x 2dBi LTE Antennas
  • FREE TechnoRV Learning Series for Pepwave Routers
  • FREE TechnoRV Customer Support

 RECOMMENDED EXTERNAL ANTENNA OPTIONS:








* Cellular modem: CAT 6 (300 Mbps downlink/ 150 Mbps uplink)
* WAN Interface: 1x 10/100/1000M Ethernet; 1x Embedded Cellular Modem with Redundant SIM Slots
* LAN Interface: 2x 10/100/1000M Ethernet
* Wi-Fi interface: Simultaneous Dual-Band (2.4GHz / 5GHz); Wi-Fi 5, 2X2 MIMO; Wi-Fi WAN and/or AP
* SpeedFusion features: Hot Failover; WAN Smoothing
* Router throughput: 300 Mbps
* Recommended no. of users: 1-60
* Warranty: 1 year with option to extend annually

COMPATIBLE EXTERNAL ANTENNA OPTIONS:
* Permanent Omnidirectional 5-in-1 Antenna (4x4 MIMO, 2 WiFi, 1 GPS): Pepwave Mobility 22G 5-in-1 MIMO Antenna
* Temporary directional antenna (2x2 MIMO): Poynting A-XPOL Directional MIMO Antenna (NOTE: The XPOL will only have 2 cellular connections so it would work to improve signal on one of the modems in your dual modem unit)

The Max BR1 Mini has a single Cat 6 cellular modem. A single cellular modem means you can only use one SIM card (cellular plan) at a time to access the internet.
Note: This unit takes the smallest "Nano" SIM card.

Although the Max BR1 Mini only has one cellular modem, it allows you to use 2 SIM cards (cellular plans) in the one modem and switch between the two plans as needed. This allows for the redundancy often needed to stay connected while on the road. You can also set limits and rules for when you want to use one cell plan over the other which is a great feature when you are trying to conserve one plan and only use it as a backup. You are not using both cell plans at the same time with this router; however, there are routers available that allow you to use 2 SIM cards at the same time which will improve your connectivity. (See the Max Transit DUO routers.)

What is the optional Failover License?

The Max BR1 Mini does not come out of the box with WiFi as WAN capabilities, which means you cannot use it to access campground or local WiFi networks. You can add an optional failover software license for $99, which enables Ethernet and unlocks the WiFi as WAN feature. The failover license will allow you to use the BR1 Mini to connect to campground WiFi using a dual band connection (2.4 and 5 GHz).

If you plan to use your Max BR1 Mini for cellular only, then you do not need to purchase the additional $99 failover license. If you choose to not add it at the time of purchase, don’t worry; you can add it at any time.
This is a digital item that is permanently connected to the router it is purchased for. For this reason, failover licenses are nonrefundable and nontransferrable.

Supports All Major Carrier Networks
US Carriers: AT&T, Verizon, T-Mobile, Sprint, and US Cellular
International Carriers: Rogers, TELUS, and Bell

Supports Carrier Aggregation:

Cat 6 routers like the Max BR1 Mini support Carrier Aggregation (CA), which means they have the ability to connect to 2 cellular bands at the same time. By combining more than one cellular band together, it is possible to increase the bandwidth available. With the Max BR1 Mini you can choose which primary band you want to use (the tower selects the second) which allows you to avoid the crowded primary band used by phones and hotspots. To see the bands supported by the Max BR1 Mini, see the specs listed below.

Increased Throughput and Speeds:

Because of Carrier Aggregation, the Max BR1 Mini has higher throughput and speeds than a Cat 4 router or phone.

The Max BR1 Mini has theoretical download speeds of 300 Mbps and upload speeds of 50 Mbps.
This router features Wifi 6, the latest and greatest wifi technology, promising faster, more efficient wifi performance.
